Transparent Glass Floor Specification

Views: 233     Author: Site Editor     Publish Time: 2018-02-22      Origin: Site

1. High transparency: artistic, practical, widely applicable

2. It adopts the technology of toughing treatment.

3. It can easily hold body weight and max load is over 630KG.

4. It’s the same size with ordinary raised floor so it can be used together with other floors.

5. With antistatic function, it can be used in data center.

6. Size:600*600*15-40 mm, customizable as per the thickness of antistatic raised floor.



Advantage:

1. Antistatic function;

2. It adopts the technology of toughing treatment, which strengthens load capacity and static performance. Situation under the floor can be easily inspected without moving the panel, which saves labor and time as well;

3. The arrangement of cables, conditioner water leakage, etc can be clearly, directly and simply inspected to eliminate potential safety hazard.


Frameless Glass Raised Floor

Deflection

Loading capacity

Permanent deflection

Size(mm)

0.5mm

120KG

0.5mm

600*600*30

1.0mm

250KG

1.5mm

370KG

2.0mm

480KG

2.5mm

630KG
