Heavy Duty Aluminium Raised Access Floor
	Model No.	1000/Series	1200/Series	1500/Series	1000 Series Grid type
1	Concentrated load kgf/6.45cm² ≤2.0mm	1000	1200	1500	1000
2	Ultimated load kgf/6.45cm² ≤2.0mm	2000	2400	3000	2000
3	Uniform load kgf/m² ≤1.0mm	3000	3600	4500	3000
4	Open ratio	0%、17%、25%	0%、17%、25%	0%、17%、25%	50%
5	Surface material	HPL、PVC with fireproof performance,SUS304 is optional;			Epoxy surface treatment
6	Surface material ESD standards	Electrostatic conductive PVC:10⁴-106Q&10⁶-109Ω			Electrostatic conductive,<1*10⁹ Ω
7	Base material	Die casting Aluminium,ADC12
8	Length/width tolerance	600+0.00mm/600-0.20mm
9	Thickness tolerance	±0.10mm
10	Planeness tolerance	±0.20mm
11	Diagonal tolerance	Max.0.50mm
