Availability: | |
---|---|
1. Antistatic, high dimensional precision, fireproof, high load capacity, flatness and shockproof
2. Elegant appearance for various top tiles like HPL, PVC, ceramic, marble, granite, wood floor
3. Agreeable solution to ground air conditioning system
4. Recyclable, convenient removing, cost saving, long performance life
5. Adjustable height of pedestal, stringer connect, assembly agility, large wire and good exchangeability
6. Panel size 600*600 and 24’*24’ available
1. Antistatic, high dimensional precision, fireproof, high load capacity, flatness and shockproof
2. Elegant appearance for various top tiles like HPL, PVC, ceramic, marble, granite, wood floor
3. Agreeable solution to ground air conditioning system
4. Recyclable, convenient removing, cost saving, long performance life
5. Adjustable height of pedestal, stringer connect, assembly agility, large wire and good exchangeability
6. Panel size 600*600 and 24’*24’ available
1. Antistatic, high dimensional precision, fireproof, high load capacity, flatness and shockproof
2. Elegant appearance for various top tiles like HPL, PVC, ceramic, marble, granite, wood floor
3. Agreeable solution to ground air conditioning system
4. Recyclable, convenient removing, cost saving, long performance life
5. Adjustable height of pedestal, stringer connect, assembly agility, large wire and good exchangeability
6. Panel size 600*600 and 24’*24’ available
1. Antistatic, high dimensional precision, fireproof, high load capacity, flatness and shockproof
2. Elegant appearance for various top tiles like HPL, PVC, ceramic, marble, granite, wood floor
3. Agreeable solution to ground air conditioning system
4. Recyclable, convenient removing, cost saving, long performance life
5. Adjustable height of pedestal, stringer connect, assembly agility, large wire and good exchangeability
6. Panel size 600*600 and 24’*24’ available
All kinds of computer room, network service room, monitoring center, electronic workshop, clean room, dustless chamber etc, and occasions demanding antistatic and air conditioning
5A class office, security union plaza, futures trading building, places demanding cabling and wiring and the aging buildings’ flooring reform
Technical Data
International | Size(mm) | Concentrated load | Impact load (N) | Ultimate load (N) | Uniform load (N/M2) | Rolling load(N) | |||
LB | N | KG | 10 times | 10000 times | |||||
FS800 | 600x600x35 | ≥800 | ≥3350 | ≥363 | ≥536 | ≥11250 | ≥16100 | 3560 | 2670 |
FS1000 | 600x600x35 | ≥1000 | ≥4550 | ≥450 | ≥670 | ≥13350 | ≥23000 | 4450 | 3560 |
FS1250 | 600x600x35 | ≥1250 | ≥5560 | ≥567 | ≥780 | ≥16680 | ≥33000 | 5560 | 4450 |
FS1500 | 600x600x35 | ≥1500 | ≥6675 | ≥670 | ≥1005 | ≥19892 | ≥34500 | 6675 | 5340 |
FS2000 | 600x600x35 | ≥2000 | ≥8900 | ≥906 | ≥1340 | ≥26700 | ≥46000 | 8900 | 7120 |
*Fireprof Class A
Standard Pedestal Specification
FFH(mm) | tube diameter(mm) | adjustment +(mm) | adjustment –(mm) |
≦600 | ф25 | 25 | 25 |
700~900 | ф32 | 25 | 25 |
1000~1500 | ф45 | 25 | 25 |
Other height could be customized.
Standard Stringer SPEC: 21x32x570mm
Granite Options
All kinds of computer room, network service room, monitoring center, electronic workshop, clean room, dustless chamber etc, and occasions demanding antistatic and air conditioning
5A class office, security union plaza, futures trading building, places demanding cabling and wiring and the aging buildings’ flooring reform
Technical Data
International | Size(mm) | Concentrated load | Impact load (N) | Ultimate load (N) | Uniform load (N/M2) | Rolling load(N) | |||
LB | N | KG | 10 times | 10000 times | |||||
FS800 | 600x600x35 | ≥800 | ≥3350 | ≥363 | ≥536 | ≥11250 | ≥16100 | 3560 | 2670 |
FS1000 | 600x600x35 | ≥1000 | ≥4550 | ≥450 | ≥670 | ≥13350 | ≥23000 | 4450 | 3560 |
FS1250 | 600x600x35 | ≥1250 | ≥5560 | ≥567 | ≥780 | ≥16680 | ≥33000 | 5560 | 4450 |
FS1500 | 600x600x35 | ≥1500 | ≥6675 | ≥670 | ≥1005 | ≥19892 | ≥34500 | 6675 | 5340 |
FS2000 | 600x600x35 | ≥2000 | ≥8900 | ≥906 | ≥1340 | ≥26700 | ≥46000 | 8900 | 7120 |
*Fireprof Class A
Standard Pedestal Specification
FFH(mm) | tube diameter(mm) | adjustment +(mm) | adjustment –(mm) |
≦600 | ф25 | 25 | 25 |
700~900 | ф32 | 25 | 25 |
1000~1500 | ф45 | 25 | 25 |
Other height could be customized.
Standard Stringer SPEC: 21x32x570mm
Granite Options
